The 6.2-liter V8 Supercharged LSA is an engine that was produced by General Motors for use in high-performance vehicles. The LSA is part of GM’s fourth-generation V8 Small Block engine family, though unlike its LS9 counterpart, it is not assembled by hand, and was instead made at GM’s Silao facilities in Mexico. The engine was used in the second-generation Cadillac CTS-V range as well as the fifth-generation Chevrolet Camaro ZL1, and is still offered as over-the-counter as a crate engine from Chevrolet Performance.
Displacement: | 6.2L / 376 cu. in. |
---|---|
Aspiration: | Supercharged |
Vehicles: | Chevrolet Camaro ZL1, Cadillac CTS-V |
Introduced: | 2009 model year |
Discontinued: | 2015 |
Predecessor: | LS3 / Gen IV Small Block |
Successor: | LT4 / Gen V Small Block |
Assembly: | St. Catharines, Ontario, Canada |
Overview
More than sheer performance, the LSA balances great power with exceptional refinement. Everything from the pistons to the aesthetic engine cover was carefully selected and tuned to deliver quiet performance. An advanced, sixth-generation Eaton supercharger with high-twist four-lobe rotors is a large contributor to the engine’s quiet high performance. It enables a broad power band with almost imperceptible operation.
GM engineers created 370 different power simulations to optimize the LSA. It has been validated beyond 100,000 miles and has accumulated more than 6,400 hours of dynamometer testing. During testing, it was run more than 270 consecutive hours at wide-open throttle without a failure, and it completed actual and simulated 24-hour track tests.
Engine highlights:
- Enhanced Cylinder Block: the 6.2L engine block used with the LSA is cast from 319-T7 aluminum and fitted with cast-iron cylinder liners.
- Compared to previous blocks, it has been strengthened 20 percent by optimizing the size of the bulkhead “windows” to take advantage of material thickness in the bulkhead. The enlarged bulkhead windows also improve bay-to-bay breathing by managing airflow inside the engine more efficiently, thereby decreasing pumping loss, or reducing resistance to the pistons’ downward movement.
- The engine block was developed with the latest math-based tools and data acquired in GM’s racing programs, and it provides an exceptionally light, rigid foundation for an impressively smooth cam-in-block engine. Its deep-skirt design helps maximize strength and minimize vibration, and its aluminum construction reduces weight approximately 100 pounds compared to a conventional cast-iron cylinder block.
- Deck Plate Honing: a precision machining process reserved for high-performance engines, is used on the LSA cylinder block to maximize engine life, reduce friction between engine parts and increase horsepower. It is advantageous in applications where cylinder head pressures are greater than average – such as with a supercharged engine – to ensure cylinder sealing and prevent scuffing of the piston against the bore wall. In the LSA engine, this means improved bore life and ring sealing. True bores and better sealing are keys to optimizing power.
- Pistons with Oil-Spray Cooling: The LSA’s pistons are aluminum-cast from a high-silicon alloy developed for its combination of strength and heat-management properties.
- Casting reduces noise-generating potential, compared to other high-performance piston materials, such as forged aluminum, and is specified when noise and vibration control is a priority.
- The hypereutectic pistons are also lighter than conventional steel, which translates to less reciprocating mass inside the engine. Less mass means greater efficiency, high-rpm capability and a feeling of immediate response as the engine builds rpm.
- Lightweight Rotating Assembly: within the LSA’s cylinder block spins a balanced, dropped-forged steel crankshaft with an eight-bolt flange to mount the flywheel.
- The eight-bolt pattern increases clamping strength compared to naturally aspirated 6.2L V-8s, which use a six-bolt crank flange.
- Forged powder-metal connecting rods link the crankshaft and pistons.
- They are forged under extreme pressure from alloy metals reduced to powder, rather the melted to liquid, for a balance of low mass and high strength.
- They reduce pressure on both the rod-end bearings and main bearings, compared to conventional rods, and allow the bearings to be optimally sized for the least amount of friction.
- High-Flow Rotocast Cylinder Heads: the LSA cylinder heads are manufactured with a unique rotocast method, which rotates the head mold as the molten alloy cools and essentially eliminates porosity, or microscopic pockets of air trapped in the casting. Rotocasting delivers a stronger part that helps maintain performance and structural integrity over the life of the engine.
- Refined Low-Lift/Low-Overlap Camshaft: a refined camshaft helps balance the 6.2L LSA’s high output with smooth, tractable low-rpm performance. The torque-enhancing benefits of the supercharger allowed engineers to develop a “softer,” lower-lift camshaft for the LSA, compared to the typical high-rev, high-power exotic car engine. The result is smoother operation at idle and during low-speed driving.
- Cast-Iron Exhaust Manifolds with Close-Coupled Catalysts: the 6.2L LSA exhaust manifolds are fabricated from a premium high-silicon, high-moly iron alloy. The material delivers excellent heat management properties, and the design ensures the high flow volume required of an engine with the LSA’s capability. Immediately downstream, the exhaust manifolds are fitted with a pair of close-coupled catalytic converters that heat quickly, achieving light-off temperature and closed-loop operations in seconds.
- Upgraded Oiling System: to ensure peak, low-friction efficiency, and to promote durability during extended high-rpm operation, the LSA has a more powerful oil pump than the naturally aspirated 6.2L LS3.
- The oil pump capacity is increased to 33.8 gallons per minute and the LSA’s six-quart oil pan is fitted with a liquid-to-air oil cooler.
- Dual-Pressure/Center-Feed Fuel System: to ensure appropriate fueling in all conditions, the LSA features a dual-pressure fuel system. The dual-pressure system reacts according to throttle application, and presents several advantages. It limits the energy used by the fuel pump at low speeds, for maximum efficiency, and it reduces operational noise. The LSA also employs a center-feed fuel rail that delivers gasoline to the center of the injector rail and each bank. This helps reduce fuel pressure variation among the injectors, as well as noise.
- Dual-pressure system delivers about 36 psi (250 kPa) at idle and low speeds.
- Electronic throttle management system can immediately increase fuel pressure to 87 psi (600 kPa) for sustained high-speed operation or wide-open throttle.
- Supercharger with Four-Lobe Rotors: state-of-the-art supercharging technology is the foundation of the LSA’s remarkable performance. The supercharger is an air pump driven by the engine’s crankshaft. It forces more air into the engine’s combustion chambers than the engine could otherwise draw on its own. The increased volume of oxygen allows the engine to efficiently process more fuel, and thus generate more power.
- Dual Brick Air-to-Liquid Intercooler: an advanced intercooling system increases the 6.2L LSA’s performance and extends its supercharger’s benefits. Similar in concept to an engine’s radiator, intercoolers cool the air pumped by the charging device into the cylinders. Cooler air is denser air, which means more oxygen in a given volume, resulting in optimal combustion and more power. Traditionally, intercoolers look like small radiators mounted somewhere outside the engine, with air fed into the engine through a plumbing network.
- The LSA’s charge cooler is integrated in the supercharger case just above the rotors, with two air-to-liquid cooling “bricks” that substantially lower the temperature of air used in the combustion process. Intercoolers are familiar features on supercharged and turbocharged engines.
- Direct-Mount Ignition Coils: the LSA’s coil-on-plug ignition features advanced coils that are smaller and lighter than those used on previous V-8s. An individual coil for each spark plug delivers maximum voltage and consistent spark density, with no variation between cylinders.
- 58X Ignition System: the LSA has an advanced 58X crankshaft position encoder to ensure that ignition timing is accurate throughout its operating range.
- The new 58X crankshaft ring and sensor provide more immediate, accurate information on the crankshaft’s position during rotation. This allows the engine control module to adjust ignition timing with greater precision, which optimizes performance and economy. Engine starting is also more consistent in all operating conditions.
Specifications
Type: | 6.2L Gen IV V8 Small Block |
Displacement: | 6162 cc (376 ci) |
Engine Orientation | Longitudinal |
Compression ratio: | 9.1:1 |
Valve configuration: | Overhead valves (2 valves per cylinder) |
Assembly site: | Silao, Mexico |
Valve lifters: | Hydraulic roller |
Firing order: | 1 – 8 – 7 – 2 – 6 – 5 – 4 – 3 |
Bore x stroke: | 103.25 x 92 mm |
Fuel system: | Sequential fuel injection |
Fuel Type: | Premium required |
Maximum Engine Speed: | 6200 RPM |
Materials | |
Block: | Cast aluminum |
Cylinder head: | A356-T6 rotocast cast aluminum |
Intake manifold: | Cast aluminum |
Exhaust manifold CTS: | High silicon / high moly cast iron |
Exhaust manifold Camaro: | Cast stainless steel |
Main bearing caps: | Nodular Iron |
Crankshaft: | Forged steel |
Camshaft: | Hollow steel |
Connecting rods: | Forged powder metal |
Additional features | |
1.9 L/rev Supercharger | |
Integrated single coolant to air intercooler | |
Piston oil spray cooling | |
Direct mount ignition coils | |
Emissions controls | |
Catalytic converter | |
Three-way catalyst | |
Positive crankcase ventilation | |
Valves per cylinder | 2 |
Bore Center (mm) | 111.76 |
Vehicle Applications
Year | Make | Model | Transmission | Power (hp / kW @ RPM) | Torque (lb-ft / Nm @ RPM) |
---|---|---|---|---|---|
2012-2015 | Chevrolet | Camaro ZL1 (Coupe and Convertible) | 6-Speed Auto (MYD-6L90) and 6-Speed Manual (MG9-TR6060) | 556 / 415 @ 6100 | 551 / 747 @ 3800 |
2008-2013 | Cadillac | CTS-V (Sedan, Coupe, Wagon) | 6-Speed Auto (MYD-6L90) and 6-Speed Manual (MG9-TR6060) | 580 / 432 @ 6100 | 556 / 745 @ 3800 |
Gen IV Small Block Engine Family
Other members of the Gen IV Small Block engine family include:
- Naturally-aspirated 6.0L V8 L76
- Naturally-aspirated 6.0L V8 L77
- Naturally-aspirated 6.0L V8 L98
- Naturally-aspirated 5.3L V8 LS4
- Naturally-aspirated 7.0L V8 LS7
- Naturally-aspirated 6.2L V8 LS3
- Naturally-aspirated 6.2L V8 L99
- Supercharged 6.2L V8 LS9
Gen IV Vortec motors for pickup trucks, consisted of the following engines:
- 6.0L V8 LY6
- 6.0L V8 L96
- 6.0L V8 LFA
- 6.0L V8 LZ1
- 4.8L V8 LY2
- 4.8L V8 L20
- 5.3L V8 LMF
- 5.3L V8 LH6
- 5.3L V8 LC9
- 5.3L V8 LY5
- 5.3L V8 LMG
- 5.3L V8 LH8
- 5.3L V8 LH9
- 6.2L V8 L92
