This page includes complete 2023 Corvete Z06 specifications, including engine, transmission, chassis, suspension, wheels, tires, exterior and interior dimensions and more.
2023 Chevrolet Corvette Z06 Specs - Engine
| Type: | 5.5L DOHC V8 Direct Injection |
| Engine RPO Code: | LT6 |
| Bore & Stroke (in / mm): | 4.104 x 3.150 / 104.25 x 80 |
| Block Material: | A319-T7 sand-cast aluminum with pressed-in iron cylinder liners and four-bolt main bearing caps |
| Oiling System: | Six stage dry sump; includes oil-spray piston cooling |
| Oil Type: | DexosR synthetic 5W50 |
| Cylinder Head Material: | A356 T6 cast aluminum |
| Combustion Chamber Volume: | 58.8cc |
| Compression Ratio: | 12.5:1 |
| Valvetrain: | Dual overhead camshafts (DOHC) with mechanical finger follower valvetrain and dual-coil valve springs |
| Valve Size Intake (in / mm): | 1.654 / 42 titanium |
| Valve Size Exhaust (in / mm): | 1.378 / 35 sodium filled |
| Fuel Delivery: | Exhaust side direct injection; max pressure: 5,076 psi (35 Mpa / 350 bar) |
| Firing Order: | 1-4-3-8-7-6-5-2 |
| Throttle Body: | Twin 87mm single bore (electronic) |
| ECU: | GM E68 (32-bit processing) |
| Power (hp / kW @ rpm): | 670 / 499.6 @ 8400 |
| Torque (lb-ft/ Nm @ rpm): | 460 / 623 @ 6300 |
2023 Chevrolet Corvette Z06 Specs - Transmission & Axle
| Type: | M1L 8-speed dual clutch (DCT) |
| Gear Ratios: | |
| First: | 2.91:1 |
| Second: | 1.76:1 |
| Third: | 1.22:1 |
| Fourth: | 0.88:1 |
| Fifth: | 0.65:1 |
| Sixth: | 0.51:1 |
| Seventh: | 0.40:1 |
| Eighth: | 0.33:1 |
| Reverse Gear: | 2.63:1 |
| Ring and Pinion Ratio | 3.55:1 |
| Final Drive Ratio: | 5.56:1 |
2023 Chevrolet Corvette Z06 Specs - Suspension
| Front Suspension: | Short/long arm (SLA) double wishbone, forged aluminum upper and cast aluminum L-shape lower control arms; monotube shock absorbers (46mm); Magnetic Selective Ride Control 4.0 available. Specific calibration with available Z07 package. Front lift with memory is available on 2LZ, 3LZ |
| Rear Suspension: | Short/long arm (SLA) double wishbone, forged aluminum upper and cast aluminum L-shape lower control arms; direct-acting stabilizer bar; monotube shock absorbers (46mm); Magnetic Selective Ride Control 4.0. Specific calibration with available Z07 package |
| Steering Type: | Variable-ratio rack-and-pinion with electric power assist; includes Active Steer Stops with available Magnetic Ride Control 4.0 |
| Steering Ratio: | 15.7:1 |
2023 Chevrolet Corvette Z06 Specs - Brakes
| Brake Type Front: | eBoost-assisted discs with Brembo six-piston/two-piece calipers |
| Brake Type Rear: | eBoost-assisted discs with Brembo four-piston/monobloc calipers |
| Standad Brake Rotor Size Front (in / mm): | 14.6 x 1.3 (370 x 34) |
| Standard Brake Rotor Size Rear(in / mm): | 15.0 x 1.3 (380 x 34) |
| Available Carbon Ceramic Brake Rotor Size Front (in / mm): | 15.7 x 1.5 (398 x 38) |
| Available Carbon Ceramic Brake Rotor Size Rear(in / mm): | 15.4 x 1.3 (390 x 34) |
2023 Chevrolet Corvette Z06 Specs - Exterior Dimensions
| Wheelbase (in. / mm): | 107.2 / 2722 |
| Overall Length (in. / mm): | 184.6 / 4688 |
| Overall Length with Carbon Fiber ground effects (in. / mm): | 185.9 / 4722 |
| Overall Width (in. / mm): | 79.7 / 2025 |
| Overall Height (in. / mm): | 48.6 / 1235 |
| Track Front (in. mm): | 66.3 / 1685 |
| Track Rear (in. mm): | 66.1 / 1678 |
2023 Chevrolet Corvette Z06 Specs - Interior Dimensions
| Headroom (in. / mm): | 37.9 / 962 |
| Legroom (in. / mm): | 42.8 / 1087 |
| Shoulder Room (in. / mm): | 54.4 / 1382 |
| Hip Room (in. / mm): | 52 / 1321 |
2023 Chevrolet Corvette Z06 Specs - Weights
| Model | Dry Weight (lb. / kg): |
| Z06 Coupe | 3500 / 1588 |
| Z06 Convertible | 3599 / 1633 |
| Coupe with Z07 Package & Carbon Fiber wheels | 3434 / 1561 |
2023 Chevrolet Corvette Z06 Specs - Capacities
| Cargo Volume (cu. ft. / L): 1 | 12.6 / 357 |
| Fuel Tank Capacity (gal / Liters): | 18.5 / 70 |
| Oil Capacity (qt): | 8 |
1. Cargo and load capacity limited by weight and distribution.
2023 Chevrolet Corvette Z06 Specs - Wheels & Tires
| Wheel Size Front: | 20-inch x 10-inch |
| Wheel Size Rear: | 21-inch x 13-inch |
| Bolt Pattern (mm): | 5 x 120 |
| Tire Size Front: | 275/30ZR20 |
| Tire Size Rear: | 345/25ZR21 |
| Tire (Standard):1 | Michelin Pilot Sport 4S ZP |
| Tire (Optional):1 | Michelin Sport Cup 2 R ZP |
| Standard Wheel: | Spider-design Titanium Satin forged aluminum wheels (SOE) |
| Available Wheels (RPO Code): | Carbon Flash-painted carbon fiber wheels (Q8Q) |
| Spider-design Black forged aluminum wheels (SOA) |
| Spider-design Satin Graphite forged aluminum wheels (SOC) |
| Spider-design Satin Graphite forged aluminum wheels with Red stripe (Non-Genuine Corvette Accessory only available on 3LZ) (SOQ) |
| Spider-design Tech Bronze forged aluminum wheels (5DK) |
| Spider-design machined-face forged aluminum wheels (SOD) |
| Visible carbon fiber wheels (ROZ) |
| Standard Bright Silver painted aluminum wheels (Q8P) |
1. Do not use summer-only tires in winter conditions, as it would adversely affect vehicle safety, performance and durability. Use only GM-approved tire and wheel combinations. Unapproved combinations my change the vehicle’s performance characteristics. For important tire and wheel information, go to: my.chevrolet.com/learn/tires/ or see your dealer
* RPO codes in paranthesis
2023 Chevrolet Corvette Z06 Specs - Safety & ADAS
| 1LZ | 2LZ & 3LZ |
| Airbags:1 | Frontal and side-impact for driver and front passenger; includes Passenger Sensing System | Frontal and side-impact for driver and front passenger; includes Passenger Sensing System |
| ADAS:2 | Rear Park Assist | Rear Park Assist |
| HD Rear Vision Camera | HD Front and Rear Vision Cameras with front curb view |
| Head-Up Display | Head-Up Display |
| | Side Blind Zone Alert |
| | Rear Cross Traffic Alert |
| Rear Camera Mirror (standard only on Convertible) | Rear Camera Mirror (standard on all models) |
1. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See your vehicle Owner’s Manual for more information.
2. Safety or driver assistance features are no substitute for the driver’s responsibility to operate the vehicle in a safe manner. Read the vehicle's owner's manual for more important feature limitations and information.
