Following are the 2019 Chevrolet Corvette ZR1 specifications:
| Type: | LT5 6.2L Supercharged V-8 with direct and port injection |
| Bore & stroke (in / mm): | 4.06 x 3.62 / 103.25 x 92 |
| Block material: | Cast aluminum |
| Cylinder head material: | Cast aluminum |
| Valvetrain: | Overhead valve, two valves per cylinder |
| Fuel delivery: | Direct and port injection |
| Horsepower (hp @ rpm): | 755 @ 6300 rpm (SAE certified) |
| Torque (lb.-ft. @ rpm): | 715 @ 4400 rpm (SAE certified) |
| Type: | 7-speed manual with Active Rev Match | 8-speed paddle-shaft automatic |
| Final Drive Ratio: | 3.42 | 2.41 |
[quicktable th=”0″] ,Manual,Automatic
City,15 MPG,13 MPG
Highway,22 MPG,23 MPG
[/quicktable]
City,15 MPG,13 MPG
Highway,22 MPG,23 MPG
[/quicktable]
[quicktable th=”0″] Front Suspension:,”Short/long arm (SLA) double wishbone, cast aluminum upper and lower control arms, transverse-mounted composite spring, Magnetic Selective Ride Control ”
Rear Suspension:,”Short/long arm (SLA) double wishbone, cast aluminum upper and lower control arms, transverse-mounted composite spring, Magnetic Selective Ride Control ”
Steering Type:,Variable-ratio rack-and-pinion with electric power assist
Turning Circle (ft. / m): ,39.2 / 11.6
[/quicktable]
Rear Suspension:,”Short/long arm (SLA) double wishbone, cast aluminum upper and lower control arms, transverse-mounted composite spring, Magnetic Selective Ride Control ”
Steering Type:,Variable-ratio rack-and-pinion with electric power assist
Turning Circle (ft. / m): ,39.2 / 11.6
[/quicktable]
[quicktable th=”0″] Brake Type:,Front and rear power-assisted discs with two-piece carbon ceramic matrix rotors; fixed six-piston aluminum front calipers and fixed four-piston aluminum rear calipers
Front Brake Rotor Size (in / mm):,15.5 / 394
Rear Brake Rotor Size (in / mm):,15.3 / 388
[/quicktable]
Front Brake Rotor Size (in / mm):,15.5 / 394
Rear Brake Rotor Size (in / mm):,15.3 / 388
[/quicktable]
[quicktable th=”0″] ,Front,Rear
Wheel Size:,19-inch x 10.5-inch,20-inch x 12-inch
Standard tires:,Michelin Pilot Super Sport run-flat,
Optional tires:,Michelin Pilot Sport Cup 2 (on optional ZTK package),
Tire Size:,P285/30ZR19,P335/25ZR20
[/quicktable]
Wheel Size:,19-inch x 10.5-inch,20-inch x 12-inch
Standard tires:,Michelin Pilot Super Sport run-flat,
Optional tires:,Michelin Pilot Sport Cup 2 (on optional ZTK package),
Tire Size:,P285/30ZR19,P335/25ZR20
[/quicktable]
[quicktable th=”0″] Wheelbase (in. / mm):,106.7 / 2710
Overall Length (in. / mm):,176.9 / 4493
Overall Width (in. / mm):,77.4 / 1965
Overall Height (in. / mm):,”48.6 / 1234
Track front (in. mm): ,63.6 / 1615
Track rear (in. mm): ,62.5 / 1588
Curb Weight (lb. / kg):,”3524 / 1598
[/quicktable]
Overall Length (in. / mm):,176.9 / 4493
Overall Width (in. / mm):,77.4 / 1965
Overall Height (in. / mm):,”48.6 / 1234
Track front (in. mm): ,63.6 / 1615
Track rear (in. mm): ,62.5 / 1588
Curb Weight (lb. / kg):,”3524 / 1598
[/quicktable]
[quicktable th=”0″] Headroom (in / mm):,38 / 962
Legroom (in. / mm):,43 / 1092
Shoulder Room (in. / mm):,55 / 1397
Hip Room (in. / mm):,54 / 1371
[/quicktable]
Legroom (in. / mm):,43 / 1092
Shoulder Room (in. / mm):,55 / 1397
Hip Room (in. / mm):,54 / 1371
[/quicktable]
[quicktable th=”0″] Fuel Tank:,18.5 gal. / 70 liters
EPA passenger volume (cu. ft. / L):,52 / 1472
Cargo volume (cu. ft. / L):,”15 / 425
[/quicktable]
EPA passenger volume (cu. ft. / L):,52 / 1472
Cargo volume (cu. ft. / L):,”15 / 425
[/quicktable]
[nggallery id=931]
