All-electric vehicles like the Chevy Equinox EV offer a number of benefits over ICE-powered vehicles, but if the onboard 12-volt battery dies, accessing the cabin could prove tricky. This is due to the fact that the door handles won’t deploy and the power locks will become inoperative once the 12-volt battery is completely drained. That said, there’s still a relatively straightforward method to unlock your vehicle manually and get back on the road.
To unlock the Chevy Equinox EV when the 12-volt battery is dead, first locate the mechanical key. This is done by removing the mechanical key from the key fob, which is accomplished by pressing the small release button at the base of the fob and pulling out the hidden mechanical key.
Next, access the liftgate key lock cylinder. Move around to the rear of the vehicle and locate the small, round rubber plug on the bottom of the liftgate. Remove this plug to reveal the manual lock cylinder, then insert the mechanical key into the cylinder and turn to unlock the liftgate.
Once the liftgate is unlocked, open it manually. Depending on your flexibility, you may need to fold down the rear seatbacks to climb into the front of the vehicle. After reaching the front, open the hood latch to access the 12-volt battery. From here, you can charge the 12-volt battery to restore vehicle functionality.
This process ensures access to your vehicle even in situations where the battery is completely drained.
The Chevy Equinox EV is designed with this manual override to provide a reliable solution in emergencies, ensuring drivers can regain access without damaging the vehicle, such as breaking a window. Note that further details are provided in the vehicle owner’s manual.
As a reminder, the Chevy Equinox EV rides on the GM BEV3 platform and is produced at the GM Ramos Arizpe plant in Mexico.
