Owners of certain examples of the 2024 GMC Sierra HD truck have reported an issue where the headlamps flash and/or the windshield wipers pause while wiping. If you find this inconvenience to be occurring with your Sierra heavy-duty pickup, here may be why.
According to a writeup on GM TechLink, the Body Control Module (BCM) communicates with the Lighting Control Module (LCM) via the Controller Area Network (CAN) bus in order to operate the headlamps and wipers. If an affected truck’s battery dips below the threshold in the LCM during a cranking event, or if the battery has been discharged and needs a jump start, the Lighting Control Module may go into a reset every eight to ten seconds, which causes the headlamps to flash.
This all makes the voltage diagnostics in the Lighting Control Module fail, which in turn throws the P0606 Diagnostic Trouble Code (DTC). From there, the best path moving forward is to test the battery following the recommended testing procedures in the appropriate Service Information, and then replace the battery as necessary. Alternatively, simply disconnecting the battery will reset the LCM.
As a reminder, the 2024 GMC Sierra HD is offered with two powerplant options, including the standard naturally aspirated 6.6L V8 L8T gasoline engine, rated at 401 horsepower and 464 pound-feet of torque, and the optional 6.6L V8 L5P turbodiesel Duramax engine, which has been uprated for the mid-cycle refresh to 470 horsepower and 975 pound-feet of torque.
Notably, both engine choices are mated to the Allison-branded 10-speed automatic transmission.
Under the body panels, the Sierra HD rides on a more capable variant of the GM T1 platform – which it shares with its corporate platform-mate, the 2024 Chevy Silverado HD. Production takes place at the GM Flint plant in Michigan.
