The GMC Yukon full-size SUV isn’t short on space or practicality, but for those customers that need that a bit more of both, the GMC Yukon XL provides. The question is this – what exactly is the difference between these two models? Now, GM Authority is lining up all the important numbers in the following comparison.
GMC Yukon
GMC Yukon XL
How They Are Similar
To begin, let’s cover what makes the GMC Yukon and GMC Yukon XL similar. The GMC Yukon nameplate received its latest fifth-generation overhaul for the 2021 model year, introducing all the usual upgrades and changes, including a new exterior design, a new interior, new tech features, and more. Both models ride on the GM T1 platform, reserved for GM’s pickup trucks and body-on-frame SUVs, and both feature an independent rear suspension.
The mechanical similarities extend to the powertrain as well, with both models offering a trio of powerplants, including the naturally aspirated 5.3L V8 L84 gasoline engine (355 horsepower, 383 pound-feet of torque), the naturally aspirated 6.2L V8 L87 gasoline engine (420 horsepower, 460 pound-feet of torque), and the 3.0L I6 LM2 turbodiesel Duramax engine (277 horsepower, 460 pound-feet of torque). Each of these powerplants connects to the GM 10-speed automatic transmission, with both RWD and 4WD offered.
The trim level lineup is also identical, and includes SLE, SLT, AT4, and Denali.
GMC Yukon
GMC Yukon XL
How They Are Different
Of course, the biggest difference between the GMC Yukon and GMC Yukon XL comes down to sizing, with the extended-length Yukon XL offering substantially more interior room than the standard GMC Yukon. Of course, that means the exterior is bigger as well, with the wheelbase stretched out by 13 inches, and the overall length stretched by more than 15 inches.
The front and rear track are wider as well, with the latter a tenth of an inch wider, and the latter two-tenths wider. Unsurprisingly, the turning diameter is wider as well.
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| Wheelbase (in.) | 134.0 | 121.0 | +13 |
| Overall Length (in.) | 225.2 | 210.0 | +15.2 |
| Overall Width (in.) | 81.0 | 81.0 | 0 |
| Overall Height (in.) | 76.5 | 76.5 | 0 |
| Front Track (in.) | 68.5 | 68.4 | +0.1 |
| Rear Track (in.) | 68.3 | 68.1 | +0.2 |
| Turning Diameter with 18-inch wheels, curb-to-curb (ft.) | 42.3 | 38.1 | +4.2 |
| Turning Diameter with 20/22-inch wheels, curb-to-curb (ft.) | 43.3 | 39.7 | +3.6 |
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| Wheelbase (mm) | 3406 | 3071 | +335 |
| Overall Length (mm) | 5720 | 5334 | +386 |
| Overall Width (mm) | 2057 | 2057 | 0 |
| Overall Height (mm) | 1943 | 1943 | 0 |
| Front Track (mm) | 1740 | 1737 | +3 |
| Rear Track (mm) | 1735 | 1730 | +5 |
| Turning Diameter with 18-inch wheels, curb-to-curb (m) | 12.9 | 11.6 | +1.3 |
| Turning Diameter with 20/22-inch wheels, curb-to-curb (m) | 13.2 | 12.1 | +1.1 |
GMC Yukon Denali
GMC Yukon XL Denali
The extra metal outside the GMC Yukon XL provides more room inside, although passengers won’t necessarily notice it, unless, of course, they’re seated in the third row, where they’ll find an extra 1.8 inches of legroom and an extra 0.1 inches of shoulder room.
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| First Row Headroom (in.) | 42.3 | 42.3 | 0 |
| First Row Legroom (in.) | 44.5 | 44.5 | 0 |
| First Row Shoulder Room (in.) | 66.0 | 66.0 | 0 |
| First Row Hip Room (in.) | 61.5 | 61.5 | 0 |
| Second Row Headroom (in.) | 38.9 | 38.9 | 0 |
| Second Row Legroom (in.) | 42.0 | 42.0 | 0 |
| Second Row Shoulder Room (in.) | 64.8 | 64.8 | 0 |
| Second Row Hip Room (in.) | 61.3 | 61.3 | 0 |
| Third Row Headroom (in.) | 38.2 | 38.2 | 0 |
| Third Row Legroom (in.) | 36.7 | 34.9 | +1.8 |
| Third Row Shoulder Room (in.) | 62.8 | 62.7 | +0.1 |
| Third Row Hip Room (in.) | 49.4 | 49.4 | 0 |
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| First Row Headroom (mm) | 1074 | 1074 | 0 |
| First Row Legroom (mm) | 1130 | 1130 | 0 |
| First Row Shoulder Room (mm) | 1676 | 1676 | 0 |
| First Row Hip Room (mm) | 1562 | 1562 | 0 |
| Second Row Headroom (mm) | 988 | 988 | 0 |
| Second Row Legroom (mm) | 1067 | 1067 | 0 |
| Second Row Shoulder Room (mm) | 1646 | 1646 | 0 |
| Second Row Hip Room (mm) | 1557 | 1557 | 0 |
| Third Row Headroom (mm) | 970 | 970 | 0 |
| Third Row Legroom (mm) | 932 | 886 | +46 |
| Third Row Shoulder Room (mm) | 1595 | 1593 | +2 |
| Third Row Hip Room (mm) | 1255 | 1255 | 0 |
GMC Yukon
GMC Yukon XL
The biggest difference between the GMC Yukon and GMC Yukon XL can be seen in cargo room, where the Yukon XL offers more than 21 cubic feet of cargo volume behind the first and second rows, and an extra 16 cubic feet behind the third row. Critically, the Yukon XL is also down on max payload capacity, although fuel tank capacity is up by 4 gallons.
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| Cargo Volume Behind First Row (cu. ft.) | 144.7 | 122.9 | +21.8 |
| Cargo Volume Behind Second Row (cu. ft.) | 93.8 | 72.6 | +21.2 |
| Cargo Volume Behind Third Row (cu. ft.) | 41.5 | 25.5 | +16 |
| Max Payload Capacity with 5.3L V8 L84 (lbs.) | 1698 | 1792 | -94 |
| Max Payload Capacity with 6.2L V8 L87 (lbs.) | 731 | 1671 | -940 |
| Max Payload Capacity with 3.0L I6 LM2 (lbs.) | 709 | 1671 | -962 |
| Max Towing Capacity with 5.3L V8 L84 (lbs.) | 8300 | 8400 | -100 |
| Max Towing Capacity with 6.2L V8 L87 (lbs.) | 8100 | 8200 | -100 |
| Max Towing Capacity with 3.0L I6 LM2 (lbs.) | 7800 | 8100 | -300 |
| Fuel Tank (gal.) | 28 | 24 | +4 |
| Dimension | 2023 GMC Yukon XL | 2023 GMC Yukon | +/- Yukon XL |
|---|---|---|---|
| Cargo Volume Behind First Row (L) | 4098 | 3480 | +618 |
| Cargo Volume Behind Second Row (L) | 2656 | 2056 | +600 |
| Cargo Volume Behind Third Row (L) | 1175 | 722.2 | +452.8 |
| Max Payload Capacity with 5.3L V8 L84 (kg) | 1698 | 813 | +885 |
| Max Payload Capacity with 6.2L V8 L87 (kg) | 1612 | 758 | +854 |
| Max Payload Capacity with 3.0L I6 LM2 (kg) | 1563 | 758 | +805 |
| Max Towing Capacity with 5.3L V8 L84 (kg) | 3765 | 3810 | -45 |
| Max Towing Capacity with 6.2L V8 L87 (kg) | 3674 | 3720 | -46 |
| Max Towing Capacity with 3.0L I6 LM2 (kg) | 3538 | 3674 | -136 |
| Fuel Tank (L) | 106 | 91 | +15 |
