2023 GMC Canyon vs. 2022 GMC Canyon: Dimensional Comparison
18
Sponsored Links
General Motors unveiled the 2023 GMC Canyon back in August of 2022, revealing an all-new third generation complete with a long list of changes and updates. Now, we’re taking a closer look at the third-gen 2023 GMC Canyon to compare it to the preceding, second-gen 2022 model year. In this comparison, we’re highlighting the exterior dimensions, interior dimensions, and cargo room, as well as capacities.
Exterior Dimensions
In terms of exterior dimensions, the new 2023 GMC Canyon is considerably larger than the preceding generation, especially with regard to overall height, where the next-gen pickup is more than 9 inches taller. The 2023 GMC Canyon also presents a much wider track, as well as a reduced front overhang that’s 2.4 inches shorter than the preceding model.
To note, the overall length for the previous-generation GMC Canyon Extended Cab / Long Bed and Crew Cab / Long Bed length was 74 inches, or 1,880 mm. Meanwhile, the 2023 GMC Canyon is only offered as a Crew Cab / Short Bed.
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Wheelbase (in.) | 131.0 | 128.0 | +3 |
| Length (in.) | 213.2 | 212.4 | +0.8 |
| Width (in.) | 72.4 | 74.3 | -1.9 |
| Height (in.) – Elevation 2WD | 79.8 | 70.7 | +9.1 |
| Height (in.) – Elevation 4WD | 79.8 | 70.6 | +9.2 |
| Height (in.) – AT4 | 79.8 | 70.6 | +9.2 |
| Height (in.) – AT4X | 81.6 | - | - |
| Height (in.) – Denali 2WD | - | 70.7 | - |
| Height (in.) – Denali 4WD | 80.4 | 70.6 | +9.8 |
| Front Track (in.) – Elevation | 66.1 | 62.4 | +3.7 |
| Front Track (in.) – AT4 | 66.1 | 62.4 | +3.7 |
| Front Track (in.) – AT4X | 66.3 | 62.4 | +3.9 |
| Front Track (in.) – Denali | 66.0 | 62.4 | +3.6 |
| Rear Track (in.) – Elevation | 66.1 | 62.4 | +3.7 |
| Rear Track (in.) – AT4 | 66.1 | 62.4 | +3.7 |
| Rear Track (in.) – AT4X | 66.3 | 62.4 | +3.9 |
| Rear Track (in.) – Denali | 65.9 | 62.4 | +3.5 |
| Front Overhang (in.) | 34.5 | 36.9 | -2.4 |
| Rear Overhang (in.) | 47.3 | 47.2 | +0.1 |
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Wheelbase (mm) | 3338 | 3259 | +79 |
| Length (mm) | 5415 | 5395 | +20 |
| Width (mm) | 1839 | 1887 | -48 |
| Height (mm) – Elevation 2WD | 2027 | 1796 | +231 |
| Height (mm) – Elevation 4WD | 2027 | 1793 | +234 |
| Height (mm) – AT4 | 2027 | 1793 | +234 |
| Height (mm) – AT4X | 2073 | - | - |
| Height (mm) – Denali 2WD | - | 1796 | - |
| Height (mm) – Denali 4WD | 2042 | 1793 | +249 |
| Front Track (mm) – Elevation | 1679 | 1585 | +94 |
| Front Track (mm) – AT4 | 1679 | 1585 | +94 |
| Front Track (mm) – AT4X | 1684 | 1585 | +99 |
| Front Track (mm) – Denali | 1676 | 1585 | +91 |
| Rear Track (mm) – Elevation | 1679 | 1585 | +94 |
| Rear Track (mm) – AT4 | 1679 | 1585 | +94 |
| Rear Track (mm) – AT4X | 1684 | 1585 | +99 |
| Rear Track (mm) – Denali | 1674 | 1585 | +89 |
| Front Overhang (mm) | 876 | 937 | -61 |
| Rear Overhang (mm) | 1201 | 1199 | +2 |
2023 GMC Canyon
2022 GMC Canyon
Interior Dimensions
Inside the cabin, the 2023 GMC Canyon is actually a bit tighter than the preceding model, with nearly every measurement showing a slight decrease, the largest of which is front headroom and rear legroom, both of which are down by 1.1 inches. Front legroom, however, is up by a modest 0.2 inches.
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Front Headroom (in.) | 40.3 | 41.4 | -1.1 |
| Front Headroom With Sunroof (in.) | 39.2 | - | - |
| Front Legroom (in.) | 45.2 | 45.0 | +0.2 |
| Front Shoulder Room (in.) | 57.4 | 57.5 | -0.1 |
| Front Hip Room (in.) | 54.7 | 55.0 | -0.3 |
| Rear Headroom (in.) | 38.3 | 38.3 | 0 |
| Rear Legroom (in.) | 34.7 | 35.8 | -1.1 |
| Rear Shoulder Room (in.) | 56.1 | 56.2 | -0.1 |
| Rear Hip Room (in.) | 53.1 | 53.3 | -0.2 |
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Front Headroom (mm) | 1024 | 1052 | -28 |
| Front Headroom With Sunroof (mm) | 996 | - | - |
| Front Legroom (mm) | 1148 | 1143 | +5 |
| Front Shoulder Room (mm) | 1458 | 1460 | -2 |
| Front Hip Room (mm) | 1389 | 1397 | -8 |
| Rear Headroom (mm) | 973 | 973 | 0 |
| Rear Legroom (mm) | 881 | 909 | -28 |
| Rear Shoulder Room (mm) | 1425 | 1427 | -2 |
| Rear Hip Room (mm) | 1349 | 1354 | -5 |
2023 GMC Canyon
Second-gen GMC Canyon
Cargo Room
Moving over to the bed, we find the 2023 GMC Canyon offers a little more space compared to an equivalent 2022 model-year pickup, with an extra 0.3 inches of bed width and an extra 1.1 inches between the wheel housings.
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Cargo Bed Length (in.) | 61.7 | 61.7 | 0 |
| Cargo Bed Width (in.) | 58.1 | 57.8 | +0.3 |
| Cargo Bed Width Between Wheelhousing (in.) | 45.5 | 44.4 | +1.1 |
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Cargo Bed Length (mm) | 1567 | 1567 | 0 |
| Cargo Bed Width (mm) | 1476 | 1468 | +8 |
| Cargo Bed Width Between Wheelhousing (mm) | 1156 | 1128 | +28 |
2023 GMC Canyon
Second-gen GMC Canyon
Capacities
Lastly, we have the capacities, where we find significant changes in place for the new 2023 model year. Ground clearance is up by as much as 2.3 inches for certain configurations, while curb weight is up as well, in particular for the Denali trim level. Max towing ratings are unchanged, although a rating of 7,700-pound rating is now standard following the departure of the base-level 2.5L I4 LCV gasoline engine offered for the 2022 GMC Canyon, which had a 3,500-pound cap. Finally, payload is up slightly, expect for Denali trim levels.
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Ground Clearance (in.) – Elevation 2WD | 9.6 | 8.3 | +1.3 |
| Ground Clearance (in.) – Elevation 4WD | 9.6 | 8.2 | +1.4 |
| Ground Clearance (in.) – AT4 | 9.6 | 8.2 | +1.4 |
| Ground Clearance (in.) – AT4X | 10.7 | - | - |
| Ground Clearance (in.) – Denali 2WD | - | 8.3 | - |
| Ground Clearance (in.) – Denali 4WD | 10.5 | 8.2 | +2.3 |
| Curb Weight (lbs.) – Elevation 2WD | 4430 | 4050 | +380 |
| Curb Weight (lbs.) – Elevation 4WD | 4630 | 4470 | +160 |
| Curb Weight (lbs.) – AT4 | 4670 | 4520 | +150 |
| Curb Weight (lbs.) – AT4X | 4970 | - | - |
| Curb Weight (lbs.) – Denali 2WD | - | 4280 | - |
| Curb Weight (lbs.) – Denali 4WD | 4860 | 4540 | +320 |
| Fuel Capacity (gal.) | 21.4 | 21.0 | +0.4 |
| Payload (lbs.) – Elevation 2WD | 1640 | 1540 | +100 |
| Payload (lbs.) – Elevation 4WD | 1590 | 1500 | +90 |
| Payload (lbs.) – AT4 | 1550 | 1450 | +100 |
| Payload (lbs.) – AT4X | 1250 | - | - |
| Payload (lbs.) – Denali 2WD | - | 1490 | - |
| Payload (lbs.) – Denali 4WD | 1360 | 1430 | -70 |
| Towing (lbs.) – Elevation | 7700 | 7700 | 0 |
| Towing (lbs.) – AT4 | 7700 | 7550 | +150 |
| Towing (lbs.) – AT4X | 6000 | - | - |
| Towing (lbs.) – Denali | 7700 | 7700 | 0 |
| Dimension | 2023 Canyon | 2022 Canyon Crew Cab Short Box | +/- 2023 Canyon vs. 2022 Canyon |
|---|---|---|---|
| Ground Clearance (mm) – Elevation 2WD | 244 | 211 | +33 |
| Ground Clearance (mm) – Elevation 4WD | 244 | 208 | +36 |
| Ground Clearance (mm) – AT4 | 244 | 208 | +36 |
| Ground Clearance (mm) – AT4X | 272 | - | - |
| Ground Clearance (mm) – Denali 2WD | - | 211 | - |
| Ground Clearance (mm) – Denali 4WD | 267 | 208 | +59 |
| Curb Weight (kg) – Elevation 2WD | 2009 | 1837 | +172 |
| Curb Weight (kg) – Elevation 4WD | 2100 | 2028 | +72 |
| Curb Weight (kg) – AT4 | 2118 | 2050 | +68 |
| Curb Weight (kg) – AT4X | 2254 | - | - |
| Curb Weight (kg) – Denali 2WD | - | 1941 | - |
| Curb Weight (kg) – Denali 4WD | 2204 | 2059 | +145 |
| Fuel Capacity (L) | 81 | 79 | +2 |
| Payload (kg) – Elevation 2WD | 744 | 699 | +45 |
| Payload (kg) – Elevation 4WD | 721 | 680 | +41 |
| Payload (kg) – AT4 | 703 | 658 | +45 |
| Payload (kg) – AT4X | 567 | - | - |
| Payload (kg) – Denali 2WD | - | 676 | - |
| Payload (kg) – Denali 4WD | 617 | 649 | -32 |
| Towing (kg) – Elevation | 3493 | 3493 | 0 |
| Towing (kg) – AT4 | 3493 | 3425 | +68 |
| Towing (kg) – AT4X | 2722 | - | - |
| Towing (kg) – Denali | 3493 | 3493 | 0 |
