Most GM cars – not utility vehicles or trucks, but passenger cars – now leave the factory with a tire inflator kit rather than a spare wheel. This is done for several reasons, primarily to decrease vehicle weight and increase fuel economy. Given the increased popularity of including the tire inflator kit in place of an actual spare, GM Authority is providing a detailed overview of the tool, and how to use it.
Tire Inflator Kit Content
The kit includes the following components:
- Storage bag
- Sealant canister inlet valve
- Sealant/air hose
- Air only hose
- Tire sealant (aka the “goop”) canister and base
- Power plug
- On/off button
- Slot on top of compressor
- Pressure deflation button
- Pressure gauge
Using Inflator Kit And Tire Sealant Together
Those who intend to use the tire sealant and compressor kit to temporarily seal and inflate a punctured tire should follow these steps:
- Remove the tire sealant canister (4) and compressor from its storage location.
- Remove the air only hose (10) and power plug (9) from the bottom of the compressor.
- Place the compressor on the ground near the flat tire.
- Remove the valve stem cap from the flat tire by turning it counterclockwise
- Attach the air only hose (10) to the sealant canister inlet valve (1) by turning it clockwise until tight.
- Slide the base of the tire sealant canister (3) into the slot on the top of the compressor (6) to hold it upright.
Make sure the tire valve stem is position close to the ground so the hose will reach it. - Attach the sealant/air hose (2) to the tire valve stem by turning it clockwise until tight.
- Plug the power plug (9) into the accessory power outlet in the vehicle. Unplug all items from other accessory power outlets.
If the vehicle has an accessory power out let, do not use the cigarette light.
If the vehicle only has a cigarette lighter, then use it.
Note: Do not pinch the power plug cord in the door or window. - Start the vehicle. The vehicle must be running while using the air compressor.
- Press the on/off button (5) to turn the tire sealant and compressor kit on.
The compressor will inject sealant and air into the tire.
The pressure gauge (8) will initially show a high pressure while the compressor pushes the sealant into the tire. Once the sealant is completely dispersed into the tire, the pressure will quickly drop and start to rise again as the tire inflates with air only. - Use the pressure gauge to ensure that the tire is inflated to the recommended inflation pressure, which can be found on the Tire and Loading Information label.
Caution: if the recommended pressure cannot be reached after approximately 25 minutes, the vehicle should not be driven further. The tire is too severely damaged and the tire sealant and compressor kit cannot inflate the tire. - Press the on/off button (5) to turn the tire sealant and compressor kit off.
Note, the tire is not yet sealed and will continue to leak air until the vehicle is driven and the sealant is distributed in the tire. Therefore, the following steps must be done immediately after.
Caution: be careful while handling the tire sealant and compressor kit as it could be warm after usage. - Unplug the power plug (9) from the accessory power outlet in the vehicle.
- Turn the sealant/air hose (2) counterclockwise to remove it from the tire valve stem.
- Replace the tire valve stem cap.
- Remove the tire sealant canister (4) from the slot on top of the compressor (6).
- Turn the air only hose (10) counterclockwise to remove it from the tire sealant canister inlet valve (1).
- Turn the sealant/air hose (2) clockwise onto the sealant canister inlet valve (1) to prevent sealant leakage.
- Return the air only hose (10) and power plug (9) back to their original storage location.
- If the flat tire was able to inflate to the recommended inflation pressure, remove the maximum speed label from the sealant canister and place it in a highly visible location.
Do not exceed the speed on this label until the damaged tire is repaired or replaced. - Return the equipment to its original storage location in the vehicle.
- Immediately drive the vehicle 5 miles (8 kilometers) to distribute the sealant in the tire.
- Stop at a safe location and check the tire pressure.
If the tire pressure has fallen more than 10 psi (68 kPa) below the recommended inflation pressure, stop driving the vehicle. The tire is too severely damage and the tire sealant cannot seal the tire.
If the tire pressure has not dropped more than 10 psi (68 kPa) from the recommended inflation pressure, inflate the tire to the recommended inflation pressure. - Wipe off any sealant from the wheel, tire, or vehicle.
- Dispose of the used tire sealant canister (4) at a local dealer or in accordance with local state codes and practices.
Replace it with a new canister from your dealer. - After temporarily sealing a tire using the tire sealant and compressor kit, take the vehicle to an authorized dealer within 100 miles (161 kilometers) of driving to have the tire repaired or replaced.
Using Inflator Kit Without Tire Sealant
To use the tire inflator kit without sealant, follow these steps:
- Remove the compressor from its storage location.
- Remove the air only hose (10) and power plug (9) from the bottom of the compressor.
- Place the compressor on the ground near the flat tire.
Make sure the tire valve stem is position close to the ground so the hose will reach it. - Remove the valve stem cap from the flat tire by turning it counterclockwise
- Attach the air only hose (10) to the sealant canister inlet valve (1) by turning it clockwise until tight.
- Plug the power plug (9) into the accessory power outlet in the vehicle.
Unplug all items from other accessory power outlets.
If the vehicle has an accessory power out let, do not use the cigarette light.
If the vehicle only has a cigarette lighter, then use it.
Note: Do not pinch the power plug cord in the door or window. - Start the vehicle. The vehicle must be running while using the air compressor.
- Press the on/off button (5) to turn the tire inflator kit on.
The compressor will inflate the tire with air only. - Use the pressure gauge to ensure that the tire is inflated to the recommended inflation pressure, which can be found on the Tire and Loading Information label.
Caution: if the recommended pressure cannot be reached after approximately 25 minutes, the vehicle should not be driven further. The tire is too severely damaged and the tire sealant and compressor kit cannot inflate the tire. - Press the on/off button (5) to turn the tire sealant and compressor kit off.
Note, the tire is not yet sealed and will continue to leak air until the vehicle is driven and the sealant is distributed in the tire. Therefore, the following steps must be done immediately after.
Caution: be careful while handling the tire sealant and compressor kit as it could be warm after usage. - Unplug the power plug (9) from the accessory power outlet in the vehicle.
- Turn the air only hose (10) counterclockwise to remove it from the tire valve stem.
- Replace the tire valve stem cap.
- Return the air only hose (10) and power plug (9) back to their original storage location.
- Return the equipments to its original storage location in the vehicle.
Notably, the tire inflator kit also includes accessory adapters the can be used to inflate air mattresses, balls, etc. These adapters are located in a compartment located at the bottom of its housing.
